AE275/M30-1200
The 275/K4EMB 900A automatic electromechanical bollards have been designed to ensure the anti-terrorist defense. Current models are the result of our 40 years’experience in the security field and in excess of 20 years in the specific design and manufacture of automatic bollards. The 275/K4EMB 900A bollard is recommended for use in any security sensitive site like company driveways, industrial driveways, research centers, embassies, police facilities, military bases, etc..
The 275/K4EMB 900A is available with a large number of optional accessories that allow you to customize your system according to your security needs.
Bollard Use:
Control, Protect
| Product Description | |||||
|---|---|---|---|---|---|
| Automatic Bollards (Ae | AE275/K12-900 | AE275/M50-1200 | |||
| Movable Cylinder | Height | 900 mm | 1200 mm | ||
| Diameter | 271 mm | 271 mm | |||
| Material Thickness | 23 mm | 23 mm | |||
| Material | Steel S355JR Stainless steel (AISI 304) /(AISI 316) |
Steel S355JR Stainless steel (AISI 304) /(AISI 316) |
|||
| Surface Treatment | Steel version: anti-corrosion treatment - standard painting* Stainless steel version: standard painting* or brushed | Steel version: anti-corrosion treatment - standard painting* Stainless steel version: standard painting* or brushed | |||
| Reflecting Strips (Height 55 mm) | Yes | Yes | |||
| Lifting Speed | 22 cm/s | 22 cm/s | |||
| Lowering Speed | 22 cm/s | 22 cm/s | |||
| Manual Emergency Lowering | Yes | Yes | |||
| Connecting Cable to Control Unit | Standard 10 m (Max. 50 m) | Standard 10 m (Max. 50 m) | |||
| Control unit Voltage | 230/400 V AC (+/- 10%) 50/60 Hz | 230/400 V AC (+/- 10%) 50/60 Hz | |||
| Protection Category | IP 67 | IP 67 | |||
| Cycles per Day | 2,000 | 2,000 | |||
| Overall Cycles (Service Life) | Approx. 3,000,000 | Approx. 3,000,000 | |||
| Impact Energy without Destruction (Impact Resistance) | 700,000 J | 700,000 J | |||
| Impact Energy with Destruction (Breakout Resistance) | 2,000,000 J | 2,000,000 J | |||
| Load Rating (EN 124) |
D400 Regulation | D400 Regulation | |||
| Temperature Range | From -40°C to + 70°C (for low temperatures, see heating element article no. 4515342) |
From -40°C to + 70°C (for low temperatures, see heating element article no. 4515342) |
|||
| Certified According To | PAS68, IWA14-1, ASTM M50 (K12) | PAS68, IWA14-1, ASTM M50 (K12) | |||
| *For orders with no surcharge in RAL to choose, the standard colour is Anthracite grey. | |||||
| AE275/K12-900 / AE275/M50-1200 with integrated electromechanical operator
|
|||||
|---|---|---|---|---|---|
| AE275/K12-900
Article No. |
AE275/M50-1200 Article No. |
||||
| Automatic bollard AE275/K4-900/ AE275/M30-1200 | Steel painted Stainless steel painted Stainless steel brushed |
PY101093 PY107093 PY113093 |
PY101023 PY107023 PY113023 |
||
| Automatic bollard 2AE275/K4-900/ AE275/M30-1200 + Lighting strips with 25 LEDs |
Steel painted Stainless steel painted Stainless steel brushed |
PY103093 PY108093 PY115093 |
PY103023 PY108023 PY115023 |
||
| Automatic bollard 2AE275/K4-900/ AE275/M30-1200 + Lighting strips with 25 LEDs + EFO emergency function to quickly raise the bollard (in approx. 1.5 s) |
Steel painted Stainless steel painted Stainless steel brushed |
PY122093 PY123093 PY124093 |
PY122023 PY123023 PY124023 |
||
| Foundation box for automatic bollards | Article No. | ||||
| Steel foundation box with aluminium zinc coating, with counterframe and reinforcement rods |
AE275/K12-900 AE275/M50-1200 |
PY151010 PY151012 |
|||
| Stainless steel foundation box, water-tight version, with immersion pump, counterframe and reinforcement rods |
AE275/K12-900 AE275/M50-1200 |
PY151011 PY151013 |
|||
| Surcharge for upper stainless steel counterframe (AISI 304) | AA101881 | ||||
| Suspended foundation box kit for AE75/K12-M50 bollard - upper plate, frame cover and lower water-tight stainless steel foundation box (exduded chemical anchors) A TTENTIONI The bollard assembled in the suspended foundation box is not crash-test certified |
AA107151 | ||||
| Metal cap for foundation box (with screws) |
AA900851 | ||||
| Controls for automatic bollards
The specified prices are valid only when the control is supplied in combination with the bollard system |
|||||||
| Controls for bollards AE275/K4-900/ AE275/M30-1200 |
Article no |
for 1bollard PY152001 |
for 2bollards PY152002 |
for 3bollards PY152003 |
for 4bollards PY152004 |
for 5bollards PY152005 |
for 6 to 1 0 bollards PY152098 |
| Controls for bollards
with EFO emergency function AE275/K12-900 / AE275/M50-1200 Controls for more than 10 bollards without/ with EFO emergency function on request. |
Article no |
for 1bollard PY152011 |
for 2bollards PY152012 |
for 3bollards PY152013 |
for 4bollards PY152014 |
for Sbollards PY152015 |
for 6 to 1 o bollards PY152099 |
| Optional extras for automatic bollards | Article no. | |
|---|---|---|
| Surcharge for painting the cylinder in RAL to choose | AA900871 | |
| Surcharge for cylinder version in brushed stainless steel (AISI 316) | Cylinder 275-900 | AA104131 |
| Cylinder 275-1200 | AA104161 | |
| Acoustic warning signal (for bollards only in combination with LED lighting strips) | AA103261 | |
| Protection against corrosion - marine treatment - for Steel painted bollards (recommended for saline ambient conditions) | AE275/K12-900 AE27 5/M50-1200 |
AA107281 AA 107311 |
| Protection against corrosion - marine treatment - for painted stainless steel bollards (recommended for saline ambient conditions) | AE275/K12-900 AE27 5/M50-1200 |
AA107291 AA107321 |
| Protection against corrosion - marine treatment - for brushed stainless steel bollards (recommended for saline ambient conditions) | AE275/K12-900 AE27 5/M50-1200 |
AA 107301 AA107331 |
| Knurting on AE275/K12-M50 bollard with steel cylinder (difference) | Cylinder 275-900 Cylinder 275-1200 |
AA101781 AA101811 |
| Knurting on AE275/K12-M50 bollard with stainless steel cylinder (difference) | Cylinder 275-900 Cylinder 275-1200 |
AA101831 AA101821 |
| Emergency lowering in case of power failure | per control | AA107071 |
| Heating element incl. transformer and thermostat 150 W, connecting lead 10 m | AA100901 | |
| Extended connecting cable from bollard AE275-M30 / K12 / MS0 to control (max. 50 m total) supplied in 5 m increments |
Per m |
AA107111 |
| UPS device 3.0 KW - 3 KVA for further operation of 1 bollard (up to 1 hour max. and approx. 10 actuations) | BB101761 | |
| Cylinder cover (head) and reflecting strip (no logo) | difference |
AА108811 |
| Surcharge for stainless steel base plate (corrugated sheet) (AISI 304) | AA101891 | |
| Surcharge for stainless steel cylinder cover (AISI 304) |
AA101911 | |
| Surface customisation of the cylinder cover, e.g. with a city crest or a logo |
||
| Kit to modify the bollard AE275 K4/M30/K12/M50 for indined road |
AA 108151 | |
| Project inclination required (if not available) |
AA108161 |
